Dimensions |
|
|
|
|
|
|
Shearing Length |
mm |
1250 |
1500 |
2000 |
2500 |
3000 |
Shearing Capacity |
mm |
6,8,10,12 |
6,8,10,12 |
6,8,10,12 |
6,8,10,12 |
6,8,10,12 |
Depth of Gap in Frame |
mm |
150 |
150 |
150 |
150 |
150 |
Max. Back Gauge Adjustment |
mm |
800 |
800 |
800 |
800 |
800 |
Size of Blade (Blade Segment) |
mm |
1270 x 75 x 18/25 |
1525 x 75 x 18/25 |
1016 x 75 x 18/25 |
1270 x 75 x 18/25 |
1016 x 75 x 18/25 |
Length of Cut in One Stroke |
mm |
1250 |
1500 |
2000 |
2500 |
3000 |
No. of Strokes Per Minute |
No |
50 |
50 |
50 |
50 |
50 |
Power Required |
HP / RPM |
7.5, 7.5, 15, 15 / 1440 |
7.5, 10, 15, 15 / 1440 |
10,12.5,15,20 / 1440 |
10,15,20,25, / 1440 |
15,20,25,30 / 1440 |
Approx. Floor Area Required Length × Width × Height |
mm |
2300 x 2000 x 2150 |
2600 x 2000 x2150 |
3000 x 2400 x 2400 |
3650 x 3400 x 2400 |
4100 x 2600 x 2600 |
|
